CPE HT Filament - 1.75 mm - 0.75 kg
CPE HT Filament - 1.75 mm - 0.75 kg
Fiberlogy CPE HT is an odorless filament free from BPA, BPS, and styrene, making it safe for use in projects requiring potential food contact*. Thanks to its high thermal and chemical resistance, the material is perfectly suited for prints exposed to demanding conditions – such as dishwashing, chemical sterilization, or UV treatment.
CPE HT represents an attractive alternative to PC (polycarbonate) filament, offering comparable strength parameters while maintaining ease of printing and avoiding the problematic aspects of PC. It is an economical, durable, and versatile solution, ideal for industrial, laboratory, and high-temperature applications.
The production of CPE HT is carefully monitored at every stage – from raw material preparation and storage to the final filament. This guarantees consistent properties, reliable prints, and user safety even in the most demanding 3D projects.
Fiberlogy CPE HT is the filament of choice for professionals and advanced users who require a material resistant to high temperatures, chemicals, and UV radiation, while remaining easy to print and safe for contact applications.
* applies to the filament in the Pure TR version
Print settings
- Printing temperature260-280°C
- Bed temperature120°C
- Build surfaceSmooth PEI + adhesive; Textured PEI; Glass + adhesive
- Drying conditions80°C / 4h
- Enclosurenot required
- Cooling fan0-25%
Tips and recommendations
- Possible bed damage:Due to strong adhesion to the surface, printing directly on the bed or glass is not recommended, as this may cause damage. We recommend using adhesives or masking tape.
Properties
- Density1.18 g/cm³
- Tensile Strength @ Yield43 MPa (ISO 527)
- Tensile Strength @ Break58 MPa (ISO 527)
- Tensile Modulus1548 MPa (ISO 527)
- Elongation @ Yield7% (ISO 527)
- Elongation @ Break185% (ISO 527)
- Flexular Strength59 MPa (ISO 178)
- Flexular Modulus1495 MPa (ISO 178)
- Izod Impact Strength (Notched) @ 23℃93 kJ/m2 (ISO180)
- Heat Distortion Temperature @ 0.45 MPa99°C (ASTM D648)
- Heat Distortion Temperature @ 1.8 MPa85°C (ASTM D648)
